ROMI GL 240 2 Axis CNC Lathe

ROMI GL 240 2 Axis CNC Lathe

Swing over Z axis cover mm 420

Maximum cutting diameter mm 300

Maximum cutting length mm 400

Travel (X axis) mm 188

Travel (Z axis) mm 400

Spindle nose ASA A2-5"

Spindle hole diameter mm 58

Bar capacity (dia.) mm 51

Speed range rpm 6 to 6000

Rapid traverse (X & Z axis) m/min 30

Number of stations atc 12

AC spindle motor hp/kW 20/15
